Установка для исследования стойкости полупроводниковых приборов к воздействию электростатического разряда методом импульса линии передачи

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Представлена экспериментальная установка для исследования стойкости полупроводниковых приборов к воздействию электростатического разряда методом импульса линии передачи. Данная установка позволяет измерять импульсные вольт-амперные характеристики полупроводниковых приборов и защитных элементов, а также проводить исследование стойкости микроэлектронных устройств к электростатическому разряду, в том числе и без их разрушения. Установка обеспечивает создание испытательных импульсов напряжения прямоугольной формы длительностью 100 нс, согласно стандарту IEC62615, и обеспечивает амплитуду импульса тока разряда до 10 А.
