Apoptosis as a mechanism of human respiratory cell death upon exposure to carbon nanotubes

Cover Page

Cite item

Full Text

Abstract

Introduction. Carbon nanotubes (CNTs) are a group of promising nanomaterials for industrial and biomedical applications. There has been shown influence of the physicochemical characteristics of CNTs on the toxic effects, including the ability to cause DNA damage and induce apoptosis. In this study, there was carried out a comparative assessment of pro-apoptotic effects under exposure to single-walled and multi-walled CNTs produced in Russia on human respiratory cells.

Materials and methods. Human bronchial epithelial cells BEAS-2B, alveolar epithelial cells A549, and lung fibroblasts MRC5-SV40 were exposed to pristine and purified TUBALL™ SWCNTs and Taunit-M MWCNTs. In cells exposed to 4 concentrations (100, 50, 0.03, 0.0006 μg/ml) of all types of CNTs for 72 hours, the level of mRNA of the P53, BAX and BCL2 genes, as well as the level of reactive oxygen species were assessed.

Results. All types of CNTs initiated apoptosis in human respiratory epithelial cells BEAS-2B and A549, but not in MRC5-SV40 lung fibroblasts. BEAS-2B were more sensitive to the effects of MWCNTs, while A549 were more sensitive to pristine SWCNTs. Apoptosis was initiated at low concentrations, including those corresponding to industrial exposures. The mechanism of oxidative stress could act as a factor in triggering apoptosis in lung epithelial cells.

Limitations. Relatively short (72 hours) cell incubation time and the use of 2D cell models that do not consider real cell interactions.

Conclusion. There were revealed differences in the mechanisms of initiation of the internal pathway of apoptosis and sensitivity to different types of CNTs depending on the type of epithelial cells. Comparative analysis of the initiation of apoptosis by different types of CNTs has shown that there are differences in potential target cells and toxic mechanisms, which should be considered in further studies.

Compliance with ethical standards. The study does not require the submission of a biomedical ethics committee opinion or other documents.

Contribution:
Fatkhutdinova L.M. — research design, data analysis, manuscript writing and editing;
Gabidinova G.F. — review of the literature, cell cultivation, cell tests, data processing, manuscript writing;
Dimiev A.M. — development of methods for preparing suspensions of materials for introduction into cells;
Valeeva E.V. — cell tests (gene expression);
Timerbulatova G.A. — review of the literature, cell cultivation, cell tests, summarizing the results obtained manuscript writing.
All authors are responsible for the integrity of all parts of the manuscript and approval of the manuscript final version

Conflict of interest. The authors declare no conflict of interest.

Acknowledgment. The study was supported by the Russian Science Foundation grant № 22-25-00512, https://rscf.ru/project/22-25-00512/

Received: October 12, 2023 / Accepted: November 15, 2023 / Published: December 8, 2023

About the authors

Liliya M. Fatkhutdinova

Kazan State Medical University

Author for correspondence.
Email: liliya.fatkhutdinova@kazangmu.ru
ORCID iD: 0000-0001-9506-563X

MD, PhD, DSci., Head of the Department of Hygiene and Occupational Medicine, Kazan State Medical University, Kazan, 420012, Russian Federation.

e-mail: liliya.fatkhutdinova@kazangmu.ru

Russian Federation

Gulnaz F. Gabidinova

Kazan State Medical University

Email: gulnaz.gabidinova@kazangmu.ru
ORCID iD: 0000-0003-2616-5017

Ассистент кафедры гигиены, медицины труда ФГБОУ ВО Казанский ГМУ Минздрава России, 420012, Казань, Россия

e-mail:  gulnaz.gabidinova@kazangmu.ru

Russian Federation

Аirat М. Dimiev

Kazan Federal University

Email: noemail@neicon.ru
ORCID iD: 0000-0001-7497-1211

К.х.н, ведущий научный сотрудник ФГАОУ ВО «Казанский (Приволжский) федеральный университет», 420008, Казань, Россия

Russian Federation

Elena V. Valeeva

Kazan State Medical University

Email: elena.valeeva@kazangmu.ru
ORCID iD: 0000-0001-7080-3878

К.б.н., старший научный сотрудник Центральной научно-исследовательской лаборатории ФГБОУ ВО Казанский ГМУ Минздрава России, 420012, Казань, Россия

e-mail: elena.valeeva@kazangmu.ru

Russian Federation

Gyuzel A. Timerbulatova

Kazan State Medical University

Email: guzel.timerbulatova@kazangmu.ru
ORCID iD: 0000-0002-2479-2474

Старший преподаватель кафедры гигиены, медицины труда ФГБОУ ВО Казанский ГМУ Минздрава России, 420012, Казань, Россия

e-mail: guzel.timerbulatova@kazangmu.ru

Russian Federation

References

  1. Eatemadi A., Daraee H., Karimkhanloo H., Kouhi M., Zarghami N., Akbarzadeh A., et al. Carbon nanotubes: properties, synthesis, purification, and medical applications. Nanoscale Res. Lett. 2014; 9(1): 393. https://doi.org/10.1186/1556-276X-9-393
  2. Mohd Nurazzi N., Asyraf M.R.M., Khalina A., Abdullah N., Sabaruddin F.A., Kamarudin S.H., et al. Fabrication, functionalization, and application of carbon nanotube-reinforced polymer composite: an overview. Polymers (Basel). 2021; 13(7): 1047. https://doi.org/10.3390/polym13071047
  3. Ahmadi M., Zabihi O., Masoomi M., Naebe M. Synergistic effect of MWCNTs functionalization on interfacial and mechanical properties of multi-scale UHMWPE fibre reinforced epoxy composites. Comp. Sci. Technol. 2016; 134: 1–11. https://doi.org/10.1016/j.compscitech.2016.07.026
  4. Collins P.G., Avouris P. Nanotubes for electronics. Sci. Am. 2000; 283(6): 62–9. https://doi.org/10.1038/scientificamerican1200-62
  5. Maruyama B., Alam K. Carbon nanotubes and nanofibers in composite materials. Sampe J. 2002; 38(3): 59–70.
  6. Morsi M.A., Rajeh A., Al-Muntaser A.A. Reinforcement of the optical, thermal and electrical properties of PEO based on MWCNTs/Au hybrid fillers: Nanodielectric materials for organoelectronic devices. Compos. Part B Eng. 2019; 173: 106957. https://doi.org/10.1016/j.compositesb.2019.106957
  7. Ajori S., Ansari R., Darvizeh M. Vibration characteristics of single- and double-walled carbon nanotubes functionalized with amide and amine groups. Physica B Condens. Matter. 2015; 462: 8–14. https://doi.org/10.1016/j.physb.2015.01.003
  8. Hassan A.G., Mat Yajid M.A., Saud S.N., Bakar T.A., Arshad A., Mazlan N. Effects of varying electrodeposition voltages on surface morphology and corrosion behavior of multi-walled carbon nanotube coated on porous Ti-30 at. %-Ta shape memory alloys. Surf. Coat. Technol. 2020; 401: 126257. https://doi.org/10.1016/j.surfcoat.2020.126257
  9. Chen M., Zhao G., Shao L.L., Yuan Zh., Jing Q., Huang K., et al. Controlled synthesis of nickel encapsulated into nitrogen-doped carbon nanotubes with covalent bonded interfaces: the structural and electronic modulation strategy for efficient electrocatalyst in dye-sensitized solar cells. Chem. Materials. 2017; 29(22): 9680–94. https://doi.org/10.1021/acs.chemmater.7b03385
  10. Nurazzi N., Demon N., Zulaikha S. Composites based on conductive polymer with carbon nanotubes in DMMP gas sensors – an overview. Polimery. 2021; 66(2): 85–98. https://doi.org/10.14314/polimery.2021.2.1
  11. Guo F., Kang T., Liu Z., Tong B., Guo L., Wang Y., et al. Advanced lithium metal-carbon nanotube composite anode for high-performance lithium-oxygen batteries. Nano Lett. 2019; 19(9): 6377–84. https://doi.org/10.1021/acs.nanolett.9b02560
  12. Bianco A., Kostarelos K., Prato M. Applications of carbon nanotubes in drug delivery. Curr. Opin. Chem. Biol. 2005; 9(6): 674–9. https://doi.org/10.1016/j.cbpa.2005.10.005
  13. NANoREG. Validated protocols for test item preparation for key in vitro and ecotoxicity studies; 2016.
  14. Wadhwa S., Rea C., O’Hare P., Mathur A., Roy S.S., Dunlop P.S., et al. Comparative in vitro cytotoxicity study of carbon nanotubes and titania nanostructures on human lung epithelial cells. J. Hazard. Mater. 2011; 191(1–3): 56–61. https://doi.org/10.1016/j.jhazmat.2011.04.035
  15. Chetyrkina M.R., Fedorov F.S., Nasibulin A.G. In vitro toxicity of carbon nanotubes: a systematic review. RSC Adv. 2022; 12(25): 16235–56. https://doi.org/10.1039/d2ra02519a
  16. Park E.J., Zahari N.E., Lee E.W., Song J., Lee J.H., Cho M.H., et al. SWCNTs induced autophagic cell death in human bronchial epithelial cells. Toxicol. In Vitro. 2014; 28(3): 442–50. https://doi.org/10.1016/j.tiv.2013.12.012
  17. Kisin E.R., Murray A.R., Keane M.J., Shi X.C., Schwegler-Berry D., Gorelik O., et al. Single-walled carbon nanotubes: geno- and cytotoxic effects in lung fibroblast V79 cells. J. Toxicol. Environ. Health A. 2007; 70(24): 2071–9. https://doi.org/10.1080/15287390701601251
  18. Clift M.J., Endes C., Vanhecke D., Wick P., Gehr P., Schins R.P., et al. A comparative study of different in vitro lung cell culture systems to assess the most beneficial tool for screening the potential adverse effects of carbon nanotubes. Toxicol. Sci. 2014; 137(1): 55–64. https://doi.org/10.1093/toxsci/kft216
  19. Kaina B. DNA damage-triggered apoptosis: critical role of DNA repair, double-strand breaks, cell proliferation and signaling. Biochem. Pharmacol. 2003; 66(8): 1547–54. https://doi.org/10.1016/s0006-2952(03)00510-0
  20. Wang J.Y.J. DNA damage and apoptosis. Cell Death Diff. 2001; 8(11): 1047–8. https://doi.org/10.1038/sj.cdd.4400938
  21. Basu A., Haldar S. The relationship between BcI2, Bax and p53: consequences for cell cycle progression and cell death. Mol. Hum. Reprod. 1998; 4(12): 1099–109. https://doi.org/10.1093/molehr/4.12.1099
  22. Nam C.W., Kang S.J., Kang Y.K., Kwak M.K. Cell growth inhibition and apoptosis by SDS-solubilized single-walled carbon nanotubes in normal rat kidney epithelial cells. Arch. Pharm. Res. 2011; 34(4): 661–9. https://doi.org/10.1007/s12272-011-0417-4
  23. Patlolla A., Knighten B., Tchounwou P. Multi-walled carbon nanotubes induce cytotoxicity, genotoxicity and apoptosis in normal human dermal fibroblast cells. Ethn. Dis. 2010; 20(1 Suppl. 1): S1-65-72.
  24. Srivastava R.K., Pant A.B., Kashyap M.P., Kumar V., Lohani M., Jonas L., et al. Multi-walled carbon nanotubes induce oxidative stress and apoptosis in human lung cancer cell line-A549. Nanotoxicol. 2011; 5(2): 195–207. https://doi.org/10.3109/17435390.2010.503944
  25. Ghosh M., Murugadoss S., Janssen L., Cokic S., Mathyssen C., Van Landuyt K., et al. Distinct autophagy-apoptosis related pathways activated by Multi-walled (NM 400) and Single-walled carbon nanotubes (NIST-SRM2483) in human bronchial epithelial (16HBE14o-) cells. J. Hazard. Mater. 2020; 387: 121691. https://doi.org/10.1016/j.jhazmat.2019.121691
  26. Timerbulatova G., Boichuk S., Dunaev P., Porfiryeva N.N., Fatkhutdinova L.M., Dimiev A., et al. Dispersion of single-walled carbon nanotubes in biocompatible environments. Nanotechnol. Russ. 2020; 15(7–8): 437–44. https://doi.org/10.1134/S1995078020040163 https://elibrary.ru/biepnl
  27. Khamidullin T., Galyaltdinov Sh., Valimukhametova A., Brusko V., Khannanov A., Maat S., et al. Simple, cost-efficient and high throughput method for separating single-wall carbon nanotubes with modified cotton. Carbon. 2021; 178: 157–63. https://doi.org/10.1016/j.carbon.2021.03.003
  28. Timerbulatova G.A., Dunaev P.D., Dimiev A.M., Gabidinova G.F., Khaertdinov N.N., Fakhrullin R.F., et al. Comparative characteristics of various fibrous materials in in vitro experiments. Kazanskiy meditsinskiy zhurnal. 2021; 102(4): 501–9. https://doi.org/10.17816/KMJ2021-501 https://elibrary.ru/wlppem (in Russian)
  29. Predtechenskiy M.R., Khasin A.A., Bezrodny A.E., Bobrenok O.F., Dubov D.Yu., Muradyan V.E., et al. New perspectives in SWCNT applications: Tuball SWCNT. Part 1. Tuball by itself – All you need to know about it. Carbon Trends. 2022; 8: 100175. https://doi.org/10.1016/j.cartre.2022.100175
  30. Gabidinova G.F., Timerbulatova G.A., Daminova A.G., Galyaltdinov Sh.F., Dimiev A.M., Kryuchkova M.A., et al. Evaluation of the impact of industrial single-walled and multi-walled carbon nanotubes on human respiratory tract epithelial cells. Gigiena i Sanitaria (Hygiene and Sanitation, Russian journal). 2022; 101(12): 1509–20. https://doi.org/10.47470/0016-9900-2022-101-12-1509-1520 https://elibrary.ru/ivtviw (in Russian)
  31. Mohammadinejad R., Moosavi M.A., Tavakol S., Vardar D.Ö., Hosseini A., Rahmati M., et al. Necrotic, apoptotic and autophagic cell fates triggered by nanoparticles. Autophagy. 2019; 15(1): 4–33. https://doi.org/10.1080/15548627.2018.1509171
  32. Gmoshinskiy I.V., Khotimchenko S.A., Riger N.A., Nikityuk D.B. Carbon nanotubes: mechanisms of the action, biological markers and and in vivo toxicity assessment (review of literature). Gigiena i Sanitaria (Hygiene and Sanitation, Russian journal). 2017; 96(2): 176–86. https://doi.org/10.18821/0016-9900-2017-96-2-176-186 https://elibrary.ru/yirfel (in Russian)
